1 / 5Storage Silos (Large Storage System)
Storage & Bulk HandlingProduct Introduction
Our Storage Silos are large-capacity, engineered bulk storage systems designed for flour, grain, starch, sugar, chemicals, cement, and other dry bulk materials. Available in MS and SS construction with capacities from 5 tonnes to 500+ tonnes, they are fully customisable with discharge aids, level indicators, and integrated extraction systems for seamless plant integration.
What This Machine Does
This storage and bulk handling system provides intermediate or long-term storage for raw materials and finished products. It includes hoppers, silos, and bins with controlled discharge mechanisms.
Products You Can Make
This machine is designed to process and package a wide range of products:
Technical Parameters
| Capacity | 5 tonnes – 500+ tonnes |
| Diameter | 1 m – 8 m (custom) |
| Height | Up to 20 m |
| Material | Mild Steel (epoxy-coated) / SS 304 / SS 316 |
| Cone Angle | 60° – 70° (mass flow design) |
| Discharge Aids | Vibrator, air pad, screw extractor, rotary valve |
| Level Indicators | Ultrasonic / Paddle / Load cell based |
| Roof Type | Flat / Conical / Dome (with vent and access hatch) |
Flow Chart
Bulk Material Delivery (truck/pneumatic) → Inlet Valve → Silo Storage → Level Monitoring → Discharge Valve / Rotary Valve → Conveying System → Process
Line Features & Advantages
- Mass flow cone design ensures first-in-first-out (FIFO) product rotation
- Discharge aids (air pads, vibrators, screw extractors) prevent bridging and rat-holing
- Ultrasonic or load cell level monitoring for real-time inventory management
- Explosion-relief venting and earth-bonding options for combustible dust products
- Seismic and wind load designed in compliance with IS / BS / EN standards
- Complete systems supplied with conveying, extraction, and dust collection integration
Frequently Asked Questions
Q: What is the difference between a mass flow and funnel flow silo?
A: Mass flow silos have a steep cone angle (60°+) ensuring all material moves uniformly — no dead zones, ideal for products that degrade or cake. Funnel flow silos have a shallower cone and are suitable for free-flowing products where FIFO is not critical.
Q: Can I use a silo for hygroscopic (moisture-absorbing) materials?
A: Yes, with sealed inlet and outlet valves, breather filters on the vent, and optional nitrogen blanketing, our silos can store moisture-sensitive and hygroscopic bulk materials like starch, sugar, and hygroscopic chemicals.
Q: What is the production capacity of the Storage Silos (Large Storage System)?
A: The Storage Silos (Large Storage System) is available in multiple capacity configurations to match your production requirements. Contact our engineering team for customized capacity specifications and throughput details.
Q: What are the power requirements for the Storage Silos (Large Storage System)?
A: Power requirements vary based on the specific model and capacity selected. Our Storage Silos (Large Storage System) models are designed for energy-efficient operation. Contact us for detailed electrical specifications for your chosen configuration.
